About BSPL Stainless Steel Square Bar
Bhavya Stainless Private Limited (BSPL) is a leading manufacturer and supplier of Stainless Steel Square Bar.
Benefits of Stainless Steel Square Bar:
Because of the strength of the bar, the Stainless Steel Square Bar of any grade of steel is employed. Geometrically, square bars are stronger and can resist more stress than round bars.
As a result, under requirements such as the Stainless Steel 316 Square Bar, the material is employed in pressure vessel applications and general corrosive services. The various polishes, such as brilliant, black, and polished, provide the bars with distinct application capabilities. The weight of the material is determined by the breadth, diameter, length, and density of the material grade employed.
The diameter of a standard stainless steel Square Bar spans from 12mm to 45mm. They are long-lasting, heat resistant, low-maintenance, impact-resistant, and versatile. As a result, the bars have all of the attributes that are recommended by the industries. BSPL has gained a reputation for producing products of unrivaled quality that are devoid of brittle failures and corrosion and are extremely ductile. There are several grades of stainless steel, such as 304 and 316.
Because of their flexibility, stainless steel square bars are an essential component in the manufacturing and engineering industries. Our bars are of good quality, easy to cut, and have excellent workability and machinability. Our bar goods, like stainless steel alloys, have outstanding corrosion resistance.
Applications of Stainless Steel Square Bar:
Stainless Steel Square Bar is the most versatile and commonly used stainless steel, with more items, shapes, and treatments available than any other. It has exceptional forming and welding properties. Steel Square Bar's balanced austenitic structure allows it to be severely deep drawn without intermediate annealing, making it the dominating grade in the fabrication of drawn stainless items such as sinks, hollow-ware, and saucepans. Typical applications include the manufacturing of framework, support, axles, and braces, as well as applications in medical, oil and gas, construction, and architectural sectors.
Bar Standards | ASTM A276, ASTM A479, AMS 5513, AMS 5511, AMS 5647 |
Bar Dimensions | EN, DIN, JIS, ASTM, BS, ASME, AISI |
SS Square Bar Sizes | Size : 6 x 6mm – 100 x 100mm, or as customer's requirements / Length : 3 meter, 6 meter, 36 meter, 18 meter etc. |
Thickness/Diameter | 3-4 inch, 1-2 inch, 2-3 inch |
Bars Condition | Hardened & tempered, annealed |
Bar Tolerance | H8, H9, H10, H11, H12, H13K9, K10, K11, K12 or as per clients’ requirements |
Bars Finish | Cold (bright) drawn, centreless ground, hot rolled, smooth turned, peeled, slit rolled edge, hot rolled annealed, Rough Turned, bright bars, Polish, Grinding, Centreless Ground & Black |
Cold Rolled Bar Technique | Stainless Steel Hot Rolled, Cold Drawn, Cold Rolled, Forged Square Bar, Rod |
Bars Shape | Square |
Material Equivalent Chart
USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
201 | SUS 201 | |||||||||
301 | Z 12 CN 17-07 | X 12 CrNi 17 7 | 1.4310 | X 12 CrNi 1707 | SUS 301 | X 12 CrNi 17-07 | 23 31 | 301S21 | X 12 CrNi 17 7 | |
302 | Z 10 CN 18-09 | X 5 CrNi 18 7 | 1.4319 | X 10 CrNi 1809 | SUS 302 | 12KH18N9 | X 10 CrNi 18-09 | 23 31 | 302S25 | X 10 CrNi 18 9 |
303 | Z 10 CNF 18-09 | X 10 CrNiS 18 9 | 1.4305 | X 10 CrNiS 1809 | SUS 303 | X 10 CrNiS 18-09 | 23 46 | 303S21 | X 10 CrNiS 18 9 | |
303 Se | Z 10 CNF 18-09 | X 10 CrNiS 1809 | SUS 303 Se | 12KH18N10E | X 10 CrNiS 18-09 | 303S41 | ||||
304 | Z 6 CN 18-09 | X 5 CrNi 18 10 X 5 CrNi 18 12 | 1.4301 1.4303 | X 5 CrNi 1810 | SUS 304 | 08KH18N10 06KH18N11 | X 6 CrNi 19-10 | 23 32 | 304S15 304S16 | X 6 CrNi 18 10 |
304 N | X 5 CrNiN 1810 | SUS 304N1 | ||||||||
304 H | X 8 CrNi 1910 | SUS F 304H | X 6 CrNi 19-10 | |||||||
304 L | Z 2 CN 18-10 | X 2 CrNi 18 11 | 1.4306 | X 2 CrNi 1911 | SUS 304L | 03KH18N11 | X 2 CrNi 19-10 | 23 52 | 304S11 | X 3 CrNi 18 10 |
Z 2 CN 18-10-Az | X 2 CrNiN 18 10 | 1.4311 | X 2 CrNiN 1811 | SUS 304LN | 23 71 | |||||
305 | Z 8 CN 18-12 | X 8 CrNi 1812 | SUS 305 | X 8 CrNi 18-12 | 23 33 | 305S19 | X 8 CrNi 18 12 | |||
Z 6 CNU 18-10 | SUS XM7 | X 6 CrNiCu 18 10 4 Kd | ||||||||
309 | Z 15 CN 24-13 | X 15 CrNiS 20 12 | 1.4828 | X 16 CrNi 2314 | SUH 309 | 309S24 | X 15 CrNi 23 13 | |||
309 S | X 6 CrNi 2314 | SUS 309S | 20KH23N18 | X 6 CrNi 22 13 | ||||||
310 | X 12 CrNi 25 21 | 1.4845 | X 22 CrNi 2520 | SUH 310 | 10KH23N18 | 310S24 | ||||
310 S | Z 12 CN 25-20 | X 12 CrNi 25 20 | 1.4842 | X 5 CrNi 2520 | SUS 310S | 20KH25N20S2 | 23 61 | X 6 CrNi 25 20 | ||
314 | Z 12 CNS 25-20 | X 15 CrNiSi 25 20 | 1.4841 | X 16 CrNiSi 2520 | X 15 CrNiSi 25 20 | |||||
316 | Z 6 CND 17-11 | X 5 CrNiMo 17 12 2 | 1.4401 | X 5 CrNiMo 1712 | SUS 316 | X 6 CrNiMo 17-12-03 | 23 47 | 316S31 | X 6 CrNiMo 17 12 2 | |
316 | Z 6 CND 17-12 | X 5 CrNiMo 17 13 3 | 1.4436 | X 5 CrNiMo 1713 | SUS 316 | X 6 CrNiMo 17-12-03 | 23 43 | 316S33 | X 6 CrNiMo 17 13 3 | |
316 F | X 12 CrNiMoS 18 11 | 1.4427 | ||||||||
316 N | SUS 316N | |||||||||
316 H | X 8 CrNiMo 1712 | SUS F 316H | X 5 CrNiMo 17-12 | |||||||
316 H | X 8 CrNiMo 1713 | 03KH17N14M2 | X 6 CrNiMo 17-12-03 | |||||||
316 L | Z 2 CND 17-12 | X 2 CrNiMo 17 13 2 | 1.4404 | X 2 CrNiMo 1712 | SUS 316L | X 2 CrNiMo 17-12-03 | 23 48 | 316S11 | X 3 CrNiMo 17 12 2 | |
Z 2 CND 17-12-Az | X 2 CrNiMoN 17 12 2 | 1.4406 | X 2 CrNiMoN 1712 | SUS 316LN | 03KH16N15M3 | |||||
316 L | Z 2 CND 17-13 | X 2 CrNiMo 18 14 3 | 1.4435 | X 2 CrNiMo 1713 | X 2 CrNiMo 17-12-03 | 23 53 | 316S13 | X 3 CrNiMo 17 13 3 | ||
Z 2 CND 17-13-Az | X 2 CrNiMoN 17 13 3 | 1.4429 | X 2 CrNiMoN 1713 | 08KH17N13M2T 10KH17N13M2T | 23 75 | |||||
Z6 CNDT 17-12 | X 6 CrNiMoTi 17 12 2 | 1.4571 | X 6 CrNiMoTi 1712 | 08KH17N13M2T 10KH17N13M2T | X 6 CrNiMoTi 17-12-03 | 23 50 | 320S31 | X 6 CrNiMoTi 17 12 2 | ||
X 10 CrNiMoTi 18 12 | 1.4573 | X 6 CrNiMoTi 1713 | 08KH16N13M2B | X 6 CrNiMoTi 17-12-03 | 320S33 | X 6 CrNiMoTI 17 13 3 | ||||
Z 6 CNDNb 17-12 | X 6 CrNiMoNb 17 12 2 | 1.4580 | X 6 CrNiMoNb 1712 | 09KH16N15M3B | X 6 CrNiMoNb 17 12 2 | |||||
X 10 CrNiMoNb 18 12 | 1.4583 | X 6 CrNiMoNb 1713 | X 6 CrNiMoNb 17 13 3 | |||||||
317 | X 5 CrNiMo 1815 | SUS 317 | 23 66 | 317S16 | ||||||
317 L | Z 2 CND 19-15 | X 2 CrNiMo 18 16 4 | 1.4438 | X 2 CrNiMo 1815 | SUS 317L | 23 67 | 317S12 | X 3 CrNiMo 18 16 4 | ||
317 L | Z 2 CND 19-15 | X 2 CrNiMo 18 16 4 | 1.4438 | X 2 CrNiMo 1816 | SUS 317L | 23 67 | 317S12 | X 3 CrNiMo 18 16 4 | ||
330 | Z 12NCS 35-16 | X 12 NiCrSi 36 16 | 1.4864 | SUH 330 | 08KH18N10T | |||||
321 | Z 6 CNT 18-10 | X 6 CrNiTi 18 10 X 12 CrNiTi 18 9 | 1.4541 1.4878 | X 6 CrNiTi 1811 | SUS 321 | 12KH18N10T | X 6 CrNiTi 18-11 | 23 37 | 321S31 | X 6 CrNiTi 18 10 |
321 H | X 8 CrNiTi 1811 | SUS 321H | X 7 CrNiTi 18-11 | 321S20 | ||||||
329 | X 8 CrNiMo 27 5 | 1.4460 | SUS 329J1 | 08KH18N12B | 23 24 | |||||
347 | Z 6 CNNb 18-10 | X 6 CrNiNb 18 10 | 1.4550 | X 6 CrNiNb 1811 | SUS 347 | X 6 CrNiNb 18-11 | 23 38 | 347S31 | X 6 CrNiNb 18 10 | |
347 H | X 8 CrNiNb 1811 | SUS F 347H | X 7 CrNiNb 18-11 | |||||||
904L | Z 12 CNDV 12-02 | 1.4939 | ||||||||
X 20 CrNiSi 25 4 | 1.4821 | |||||||||
403 | Z 12 C 13 | X 6 Cr 13 X 10 Cr 13 X 15 Cr 13 | 1.4000 1.4006 1.4024 | X 12 Cr 13 | SUS 403 | X 6 Cr 13 | 23 02 | 403S17 | X 10 Cr 13 X 12 Cr 13 | |
405 | Z 6 CA 13 | X 6 CrAl 13 | 1.4002 | X 6 CrAl 13 | SUS 405 | X 6 CrAl 13 | 405S17 | X 6 CrAl 13 | ||
Z 8 CA 7 | X 10 CrAl 7 | 1.4713 | 10Kh13SYu | X 10 CrAl 7 | ||||||
X 10 CrAl 13 | 1.4724 | X 10 CrAl 12 | 15Kh18SYu | |||||||
X 10 CrAl 18 | 1.4742 | X 10 CrSiAl 18 | ||||||||
409 | Z 6 CT 12 | X 6 CrTi 12 | 1.4512 | X 6 CrTi 12 | SUH 409 | 409S19 | X 5 CrTi 12 | |||
X 2 CrTi 12 | 12Kh13 | |||||||||
410 | Z 10 C 13 Z 12 C 13 | X 6 Cr 13 X 10 Cr 13 X 15 Cr 13 | 1.4000 1.4006 1.4024 | X 12 Cr 13 | SUS 410 | 08Kh13 | X 12 Cr 13 | 23 02 | 410S21 | X 12 Cr 13 |
410 S | Z 6 C 13 | X 6 Cr 13 | 1.4000 | X 6 Cr 13 | SUS 410S | 23 01 | 403S17 | X 6 Cr 13 |
Stainless Steel Square Bar Size and Theoretical Weight | |||||||
Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) | Size (mm) | Weight (kg/m) |
3 × 3 | 0.071 | 15 × 15 | 1.784 | 30 × 30 | 7.137 | 60 × 60 | 28.548 |
4 × 4 | 0.127 | 16 × 16 | 2.03 | 32 × 32 | 8.12 | 63 × 63 | 31.474 |
5 × 5 | 0.198 | 17 × 17 | 2.292 | 34 × 34 | 9.167 | 67 × 67 | 35.598 |
6 × 6 | 0.285 | 18 × 18 | 2.569 | 35 × 35 | 9.714 | 70 × 70 | 38.857 |
7 × 7 | 0.389 | 19 × 19 | 2.863 | 38 × 38 | 11.451 | 75 × 75 | 44.606 |
8 × 8 | 0.508 | 20 × 20 | 3.172 | 40 × 40 | 12.688 | 80 × 80 | 50.752 |
9 × 9 | 0.642 | 21 × 21 | 3.497 | 42 × 42 | 13.989 | 85 × 85 | 52.294 |
10 × 10 | 0.793 | 22 × 22 | 3.838 | 45 × 45 | 16.058 | 90 × 90 | 64.233 |
11 × 11 | 0.96 | 24 × 24 | 4.568 | 48 × 48 | 18.271 | 95 × 95 | 71.568 |
12 × 12 | 1.142 | 25 × 25 | 4.956 | 50 × 50 | 19.825 | 100 × 100 | 79.3 |
13 × 13 | 1.34 | 26 × 26 | 5.361 | 53 × 53 | 22.275 | ||
14 × 14 | 1.554 | 28 × 28 | 6.217 | 56 × 56 | 24.868 | ||
Siding × Siding × 0.00793 = Weight (kg) per meter |
Metric Stainless Steel Square bar | 6mm, 8mm, 10mm , 12mm, 13mm, 14mm, 15mm, 16mm, 18mm, 20mm, 22mm, 25mm, 30mm, 35mm, 40mm, 45mm, 50mm, 60mm, 70mm, 75mm, 80mm, 90mm, 100mm, 120mm, 150mm |
Imperial SS Square Bar | 1/4″, 5/16″, 3/8″ 1/2″, 5/8″, 3/4″, 7/8″, 1″, 1 1/4″, 1 1/2″, 1 3/4″, 2”, 4″ |
Stainless Steel Bar Price List | FOB Price:US $2600.23/ Ton | Steel Square Bar Price List In India |
304 Stainless Steel Square Bar Price | FOB Price:US $990-3100 / Ton | Stainless Steel Square Bar Price Philippines |
Stainless Steel Square Hollow Bar Price | FOB Price:US $1145-1782 / Ton | SS Square Bar Price In Bangladesh |
SS Square Bar Price | FOB Price:US $850-4500 / Ton | Steel Square Bar Sizes Australia |
SS 304 Square Bar Price | FOB Price:US $1200-3300 / Ton | 12mm Square Bar Price In India |
Steel Square Bar Price | FOB Price:US $700-3000 / Ton | SS Square Bar Price Near Maharashtra |
Square Rod Price Per Kg | FOB Price:US $5-12 / Kg | 10mm Square Bar Price India |
Square Bar Price List | FOB Price:US $750-2700 / Ton | Stainless Steel Square Bar Nz |
Square Bar Weight
SQUARES | ||
Size(mm) | WT PER FEET IN KGS | WT PER MTR IN KGS |
16 | 0.62 | 2.05 |
18 | 0.79 | 2.59 |
20 | 0.76 | 2.49 |
22 | 1.18 | 3.87 |
25 | 1.52 | 5.00 |
28 | 1.91 | 6.27 |
30 | 2.19 | 7.20 |
32 | 2.50 | 8.19 |
36 | 3.16 | 10.37 |
38 | 3.52 | 11.55 |
40 | 3.90 | 12.80 |
45 | 4.94 | 16.20 |
50 | 6.10 | 20.00 |
56 | 7.65 | 25.08 |
60 | - | - |
65 | - | - |
70 | - | - |
75 | - | - |
80 | - | - |
90 | - | - |
100 | - | - |
SIZE in Milimeter | PERMITTED VARIATION CHART | |||
PRIMARY ROLLED | RE-ROLLED | |||
DIAMETER +/- Milimeter | OUT OF SECTION Milimeter | DIAMETER OR WIDTH ACROSS FLATS +/- Milimeter | OUT OF SECTION Milimeter | |
<=16 | 0.2 | 0.3 | ||
>16 <=26 | 0.3 | 0.5 | ||
>26 <=38 | 0.4 | 0.6 | ||
>38 <=51 | 0.5 | 0.8 | ||
>51 <=64 | 0.6 | 0.9 | ||
>64 <=76 | 0.7 | 1.1 | ||
>76 <=90 | 1.3 | 2.0 | ||
>90 <=120 | 1.5 | 2.3 | ||
>120 <=160 | 2.0 | 3.0 | ||
>160 <=200 | 2.5 | 3.8 | ||
>200 | 3.0 | 4.5 |
Square Bar Hsn Code
HSN Code is known as Harmonized System Code, developed by World Customs Organization (WCO). HSN Code also known as HTS code in USA and NCM code in Brazil, HSN code in India.
First Four Digits HSN Code Square Bar
Heading Codes | Heading Description |
7222 | Harmonized Syestem Codes Of Other Bars And Square Bars Of SS; Angles, Shapes And Sections Of Stainless Steel First Six Digits HSN Code SS Square Bar |
First Six Digits HSN Code Square Bars
HSN Codes | Description of Products |
722211 | Harmonized Syestem Codes of Of circular cross section : |
722219 | Harmonized Syestem Codes of Other : |
722220 | Harmonized Syestem Codes of Bars and rods, cold-formed/cold-finished : |
722230 | Harmonized Syestem Codes of Other bars and rods : |
722240 | Harmonized Syestem Codes of Angles, shapes and sections : |
First Eight Digits HSN Code Square Bar
HSN Codes | Description of Products |
72221111 | HSN Codes Classification of Chromium type |
72221112 | HSN Codes Classification of Nickel chromium austenitic type |
72221119 | HSN Codes Classification of Other |
72221191 | HSN Codes Classification of Chromium type |
72221192 | HSN Codes Classification of Nickel chromium austenitic type |
72221199 | HSN Codes Classification of Other |
72221911 | HSN Codes Classification of Chromium type |
72221912 | HSN Codes Classification of Nickel chromium austenitic type |
72221919 | HSN Codes Classification of Other |
72221991 | HSN Codes Classification of Chromium type |
72221992 | HSN Codes Classification of Nickel chromium austenitic type |
72221999 | HSN Codes Classification of Other |
72222011 | HSN Codes Classification of Chromium type |
72222012 | HSN Codes Classification of Nickel chromium austenitic type |
72222019 | HSN Codes Classification of Other |
72222091 | HSN Codes Classification of Chromium type |
72222092 | HSN Codes Classification of Nickel chromium austenitic type |
72222099 | HSN Codes Classification of Other |
72223011 | HSN Codes Classification of Chromium type |
72223012 | HSN Codes Classification of Nickel chromium austenitic type |
72223019 | HSN Codes Classification of Other |
72223091 | HSN Codes Classification of Chromium type |
72223092 | HSN Codes Classification of Nickel chromium austenitic type |
72223099 | HSN Codes Classification of Other |
72224010 | HSN Codes Classification of Of thickness of 80 mm and above |
72224020 | HSN Codes Classification of Of below 80 mm |
Weight Calculation
Square Bar Weight Formula 0.00623 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.0019 X ( mm ) Diam X ( mm ) Diam = Weight / Feet |
Square Bar Weight Formula
0.00788 X ( mm ) Diam X ( mm ) Diam = Weight / Meter |
Square Bar Weight Forumla 0.00680 X ( mm ) Diam X ( mm ) Diam = Weight / Meter 0.002072 X ( mm ) Width X ( mm ) Diam = Weight / Feet |
Square Bar Weight Forumla 0.00798 X ( mm ) Thickness X ( mm ) Width = Weight / Meter 0.00243 X ( mm ) Width X ( mm ) Thickness = Weight / Fee |
Searches Related to Square Bar | Square Bars We Stock & Supplied | Country / Cities |
Stainless Steel Square Bar Weight Calculator | 1/4 Stainless Steel Square Bar | Puerto Rico, Singapore, Mexico, Israel |
316 Stainless Steel Square Bar Stock | 12mm Stainless Steel Square Bar | Brazil, Hong Kong, United Arab Emirates, Russia |
Stainless Steel Square Bar Sizes Chart | 303 Stainless Steel Square Bar | Afghanistan, Tibet, Greece, South Africa |
SS Square Bar HSN Code | Square Bar 50x50 | Italy, China, Germany, Sri Lanka |
SS Square Bar Weight Chart Pdf | SS316 Square Bar | Ireland, Bolivia, Egypt, Turkey |
Square Rod Price Per Kg | SS Steel Square Bar 6mm | Belarus, Yemen, Namibia, Oman |
SS 304 Square Bar Weight Calculator | 303 SS Square Bar | Philippines, Saudi Arabia, Vietnam, Canada |
SS 304 Square Bar Price | 316 SS Square Bar | Switzerland, France, Denmark, South Korea |
SS 304 Square Bar Weight Chart | 410 SS Square Bar | Nepal, Iran, Australia, United States |
SS 304 Square Bar Size | SS Hollow Square Bar | Malaysia, Bangladesh, Thailand, Sweden |
SS316 Square Bar Weight Calculator | Steel 10mm Square Bar | Lithuania, Kuwait, United Kingdom, Bahrain |
SS 304 Square Bar Weight | Steel 3/8 Square Bar | Algeria, Libya, Nigeria, Qatar |
SS Hollow Square Bar Weight | 16mm Polished Square Rod | Poland, Austria, Bhutan, Japan |
SS Square Rod Weight Calculator | 1/8 Stainless Steel Square Rod | Czech Republic, Croatia, Nigeria, Portugal |
SS Square Rod Standard Sizes | 5/16 Stainless Steel Square Rod | Hungary, Finland, Spain, Jordan | Solid Square Steel Bar Sizes | 8mm Stainless Steel Square Rod | Mumbai, Chennai, Hyderabad, Bengaluru |
Steel Square Bar Stock Near Me | 1/4 Stainless Steel Square Rod | Pune, New Delhi, Ahmedabad, Kolkata |
SS Square Bar Standard Sizes | Half Inch Square Bar | Surat, Bangalore, Varanasi, Jaipur |
Steel Square Bar Weight | Steel Square Bar | Kannur Nagpur Vadodara, Coimbatore |
Stainless Steel Square Bar Weight | Solid Steel Square Bar | Agra, Bhagalpur, Noida, Thane |
Industrial Applications Examples
Heavy Equipment
Lifting and mobile equipment
Oil & Gas
Chemical
Steel constructions
Construction
Shipbuilding
Pylons and other architectural structures
Machine building
Vehicles and transport equipment
Power Generation
Framework structures
Construction of bridges
