About BSPL Stainless Steel 430 Coil
Bhavya Stainless Private Limited (BSPL) is a well-known producer, supplier, and exporter of high-quality 430 Stainless Steel Coils in the domestic and worldwide markets. What distinguishes us from our competition is the use of pure and high-quality raw materials, modern machinery and experienced team members, and commitment to giving complete client satisfaction.
What are the features of Stainless
Steel 430 coils?
Stainless Steel 430 Coils are non-hardened steel coils that include 17
percent chromium and 0.75 percent nickel and are classified as ferrite
steels. Because it is soft, it is virtually non-hardenable. As a result,
stainless steel 430 coils are well recognized for
industrial applications and are in great demand. The corrosion
resistance and formability of stainless steel 430 coils are well
recognized. UNS S43000 SS Coils are widely utilized in chemical
applications because of their high quality. Stainless Steel 430 Coils
must be pre-heated before any type of welding.
Post-weld annealing can improve welding strength in specific cases. In a
range of sizes, we have Hot Rolled Stainless Steel 430 Coils
and Cold Rolled Stainless Steel 430 Coils in stock. All Stainless Steel
UNS S43000 Coils are made to international standards. Because they are
heat resistant, SS 430 coils can be utilized in slightly corrosive
environments. The SS 430 coil's unique ability to resist Nitric acid
assaults makes it ideal for use in specific chemical treatments.
When annealed, stainless steel 430 coils (DIN 1.4016) harden excessively
during cold work and become Ductile. A wide range of roll forming or
mild stretch-bending procedures, as well as more conventional drawing
and bending techniques, aid in the formation of SS 430 Coils.
What are the uses of Stainless Steel 430 coils?
SS 430 coils are used in several sectors and have a wide range of
applications. SS 430 coils are used to make dishwasher linings and
refrigerator cabinet panels.
We mostly sell these high-quality SS 430 Coils to the automotive, food
processing, air conditioning sectors, pharmaceutical, and other
industries.
| SS 430 Coils Specifications | ASTM A240 / ASME SA240, BS EN 10088-2, en 10028-7, IS 6911 |
| 430 Coils Dimension Standard | MSRR, AMS, BS, JIS, AISI, ASTM, GB, DIN, EN, etc |
| SS 430 Coils Inner Diameter | 610 +0/-5 mm |
| 430 SS Coils Width | 610~2000 mm |
| SS 430 Coils Length | As per your requirement |
| SS 430 Coils Thickness | 0.31mm-100mm |
| International Standard of Stainless Steel 430 Coils | ASTM A480 ASTM A959 ASME IID EN ISO 9445 EN ISO 18286 EN 10051 EN 10088-1 ISO 15510 |
| Tolerances (width / thickness) of Stainless Steel 430 Coils | EN 10258/ DIN 59381 EN 10151 ASME SA240 430 SS Coil EN 10088 SA240 430 Coil |
| Finish of SS 430 Coils | 2B, 2D, BA NO (8), Cold rolled coil (CR), Hot rolled coil (HR), SATIN (Met with Plastic Coated), No.1 finish hot rolled, 1D, 2B, No.4, BA, 8K, satin, mirror etc. |
| Hardness | Half Hard, Soft, Hard, Quarter Hard, Spring Hard |
| Form | Coil, Strip |
| Value Added Service | Cladding, Heat Treatment, Annealed, Pickling, Polish, Rolling, Cutting, Bending, Forging, Minor Fabrication Etc. |
| Stainless Steel 430 Profiling | Plasma Plate Cutting Laser Plate Cutting Oxy-propane Flame Cutting |
Equivalent Steel Grades Comparison Chart
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN |
| SS 430 | 1.4016 | S43000 | SUS 430 | - | - |
| Type | Width | Thickness | Inner Diameter | Surface Finish |
| SS Hot Rolled No.1 Coils | 610~2000 mm | 2.5~10.0 mm | 610 +0/-5 mm | 2D, 2B, BA, No.4, No.3,No.5, HL, SB |
| SS Cold Rolled Coils | 610~1524 mm | 0.3~3.0 mm | 610 or 508 +0/-5 mm | |
| Pre-painted Stainless Steel Coils | 130-1524mm | 0.4-3.0mm | - | 2B, 2D |
| SS 430 Hot Rolled Coil Price Chart India | FOB Price:US $900-4700 / Ton | 430 Stainless Steel Coil Price In Saudi Arabia |
| SS 430 Coil Price | FOB Price:US $1500-5000 / Ton | 430 SS Coil Price In Hyderabad |
| 430 SS Coil Price | FOB Price:US $1000-3000 / Ton | 430 Stainless Steel Coil Price Philippines |
| TP430 Cold Rolled Coil Steel Prices | FOB Price:US $2400-3200 / Ton | 430 SS Coil Price In Chennai |
| 430 Stainless Steel Coil Price | FOB Price:US $1800-2500/ Ton | 430 Stainless Steel Coil Price In India |
| SS 430 Hot Rolled Coil Price Chart | FOB Price:US $1245-1986 / Ton | 430 Stainless Steel Coil Prices Australia |
| SS TP430 Coil Price | FOB Price:US $800-3500 / Ton | 430 Stainless Steel Coil Price In Sri Lanka |
| 430 SS Hot Rolled Coil Price | FOB Price:US $1000-4000 / Ton | 430 Stainless Steel Coil Price In UAE |
| SS 430 Hot Rolled Coil Price Trend | FOB Price:US $1000-5000 / Ton | 430 Stainless Steel Coil Prices Brisbane |
| Jindal SS 430 Coil Price Today | FOB Price:US $1000-3500 / Ton | 430 SS 430 Coil Price In Delhi |
| 430 SS Coil Current Price | FOB Price:US $1800-2300 / Ton | 430 Stainless Steel Coil Price Malaysia |
| 430 Hot Rolled Coil Steel Price | FOB Price:US $1000-1500 / Ton | 430 Stainless Steel Coil Prices Melbourne |
| 430 SS Cold Rolled Coil Price | FOB Price:US $1000-3000 / Ton | 430 Stainless Steel Coil Price UK |
| 430 Stainless Steel Strip Price | FOB Price:US $500-2500 / Ton | 430 SS Coil Price In Bangladesh |
| 430 SS Hot Rolled Coil Price | FOB Price:US $1000-4000 / Ton | 430 Stainless Steel Coil Price In UAE |
| SS 430 Perforated Coil Price | FOB Price:US $999-4000 / Ton | 430 SS Coil Price In Coimbatore |
| 430 Stainless Steel Coil Price In India | FOB Price:US $1000-3000 / Ton | 430 SS 430 Coil Price Per Kg In Ahmedabad |
| TP430 Stainless Steel Coil Price | FOB Price:US $1140-3015 / Ton | 430 SS 430 Coil Price Per Kg In Bangalore |
| Jindal Stainless Steel 430 Coil Price | FOB Price:US $2.1-8.8 / Piece | 430 SS Coil Price In Sri Lanka |
Types Of Finishes For Stainless Steel Coil
| Class | Definition | Application |
| No.1 | With heat treatment after hot rolling, pickling or equivalent. | Chemical tank, piping |
| No.2D | After cold rolling, carry out heat treatment and pickling or other equivalent processing. In addition, also including use of blunt surface roller to do final cold rolling slightly. | Heat exchanger, drain-pipe |
| No.2B | After cold rolling, carry out heat treatment and pickling or other equivalent processing. And use cold rolling processing to make surface brightness appropriately | Medical equipment, food industry, building materials, kitchen utensils |
| BA | After cold rolling, carry out bright heat treatment | Eat hutch appliance, electrical appliances, construction decoration |
| No.3 | Use 100# ~ 120# abrasives to do the grinding processing | Eat hutch appliance, construction decoration |
| No.4 | Use 150# ~ 180# abrasives to do the grinding processing | Eat hutch appliance, construction decoration, Medical equipment |
| No.8 | Use 600 # rotary polishing wheel to do the grinding | Mirror, decoration |
| HL | Use appropriate particle size of abrasives to do the grinding and make the surface with grinding stripe | Construction decoration |
| Surface finish | Thickness (mm) |
Width (mm) |
| 2A | 0,50 - 1,00 | 35 - 1280 |
| Bright-pickled | 0,20 - 4,00 | 30 - 1530 |
| Brushed or dull polished | 0,20 - 3,00 | 30 - 1530 |
| Bright annealed, Cold rolled | 0,05 - 3,50 | 3 - 1530 |
| Heat Treated, Cold rolled | 0,40 - 7,00 | 30 - 2000 |
| Heat Treated, Cold rolled, mech. desc. pickled | 0,30 - 7,92 | Dec-70 |
| Pickled, Heat Treated, Cold rolled | 0,20 - 6,50 | 30 - 1600 |
| Pickled, Cold rolled, Skin Passed, Heat Treated | 0,25 - 6,35 | Dec-32 |
| Heat Treated, Cold rolled, Skin Passed | 0,33 - 3,58 | 12 - 1524 |
| Ground | 0,20 - 6,00 | 12 - 1580 |
| Patterned | 0,30 - 3,50 | 30 - 1530 |
| Profile rolled | 0,40 - 1,50 | 36 - 1275 |
| Satin finish | 0,50 - 4,00 | 12 - 1580 |
| Surface coated | 0,40 - 3,00 | 30 - 1500 |
| Work hardened | 0,05 - 6,00 | 3 - 1530 |
Steel Coil Weight Chart
| Thick. on base (millimeter) | Unit Wght / Coil (kilogram) |
| 3000 x1000 x3.0 | 78.0 |
| 3000 x1250 x4.5 | 143.0 |
| 3000 x1250 x6.0 | 180.0 |
| 3000 x1250 x8.0 | 210.0 |
Coil Dimensions
| Thickness (mm) | 1000 ≤ Width < 1250 (mm) | 630 ≤ Width < 1000 (mm) | 1250 ≤ Width < 1550 (mm) |
| 0.40 ≤ T < 0.60 | ±0.035 | ±0.035 | - |
| 1.25 ≤ T < 1.60 | ±0.060 | ±0.055 | ±0.060 |
| 1.60 ≤ T < 2.00 | ±0.070 | ±0.065 | ±0.080 |
| 0.25 ≤ T < 0.40 | ±0.035 | ±0.030 | - |
| 0.80 ≤ T < 1.00 | ±0.050 | ±0.040 | ±0.050 |
| 0.60 ≤ T < 0.80 | ±0.040 | ±0.040 | - |
| 1.00 ≤ T < 1.25 | ±0.055 | ±0.050 | ±0.060 |
| Cut Edge | Mill Edge |
| Aim -0 / +1 | Aim ±10 |
| Mill Edge | Surface Finish | Cut Edge |
| 10 mm | 2B / BA | 5 mm |
| 20 mm | 2D | 10 mm |
Steel Equivalent Grades Chart
| USA | France | Germany | Germany | Italy | Japan | Russia | Spain | Sweden | UK | European Union |
| AISI | AFNOR | DIN 17006 | W.N. 17007 | UNI | JIS | GOST | UNE | SIS | BSI | EURONORM |
| 430 | Z8C17 | X6Cr17 X8Cr17 | - | X8Cr17 | SUS 430 | 12Ch17 | F.3113 | SS 2320 | 430S15 | - |
| Grade | C | Mn | Si | S | P | Cr | Mo | Ti |
| SS 430 | 0.12 max | 1 max | 1.00 max | 0.030 max | 0.04 max | 16 – 18 | - | - |
| Element | Density | Tensile Strength | Yield Strength (0.2%Offset) | Elongation | Hardness |
| SS 430 | 7.8 g/cm3 | 483 | 310 | 22 | Rockwell B (HR B)- 88 / Brinell (HB)- 0.5t |
| Stainless Steel 430 Coil Weight Calculator | Stainless Steel 430 CR Coils | Bengaluru, Mumbai, Chennai, Hyderabad |
| Searches Related to Coil | Coils We Stock & Supplied | Country / Cities |
| 430 SS Coil Slitting Near Me | 430 Stainless Steel Cold Rolled Coil | South Korea, Switzerland, France, Denmark |
| SS 430 Hot Rolled Coil Uses | 430 Stainless Steel Flat Strip | United States, Nepal, Iran, Australia |
| SS 430 Coil Rate | 430 Stainless Steel Custom Length Coil | Coimbatore, Kannur Nagpur Vadodara |
| 430 Stainless Steel Coil Supplier | 16 Gauge 430 Stainless Steel Coil | Canada, Philippines, Saudi Arabia, Vietnam |
| Jindal Steel Coil Price Per Kg | SS 430 Shim Coils | Sri Lanka, Italy, China, Germany |
| 430 S S Coil Price | 430 Polished Stainless Coils | Israel, Puerto Rico, Singapore, Mexico |
| 430 SS Coil Thickness in MM | Electropolishing Stainless Steel 430 Coils | Turkey, Ireland, Bolivia, Egypt |
| Mirror Finish Stainless Steel Coil | 3mm Stainless Steel TP430 Coil | Russia, Brazil, Hong Kong, United Arab Emirates |
| TP430 Stainless Steel Coil 2mm | Stainless Steel Tp430 2B Finish Coils | Tibet, Greece, South Africa, Afghanistan |
| 430 Stainless Steel Coil Metal Gauge Chart | 430 Stainless Steel Strip 1mm | Thailand, Sweden, Malaysia, Bangladesh |
| 430 SS Coil Hsn Code | Stainless Steel 430 HR Coils | Japan, Poland, Austria, Bhutan |
| 22 Gauge Stainless Steel 430 Coil | ASME SA240m Steel 430 Cold Rolled Coils | Qatar, Algeria, Libya, Nigeria |
| TP430 Stainless Steel Weight Per Square Meter | Brushed Stainless Steel 430 Coils | Oman, Belarus, Yemen, Namibia |
| 430 Stainless Steel Coil Length | 430 Quality Stainless Steel Coil | Jordan, Hungary, Finland, Spain |
| 430 Stainless Steel Coil Thickness Chart | 430 Stainless Steel Shim Coils | Bahrain, Lithuania, Kuwait, United Kingdom |
| SS 430 Strips | Stainless Steel 430 BA Finish Coils | Kolkata, Pune, New Delhi, Ahmedabad |
| SS 430 Coil Density | SUS 430 Coils #4 Finish | Noida, Thane, Agra, Bhagalpur |
| Jindal 430 Stainless Steel Coil Dealer | Custom Stainless Steel 430 Coils | Jaipur, Surat, Bangalore, Varanasi |
| S.S. 430 Coil Price | 430 Stainless Steel Coils Cut To Size | Nigeria, Portugal, Czech Republic, Croatia |
Industrial Applications Examples
Rail cars
Shipbuilding
Vehicles and transport equipment
Aerospace
Anti drill plates such as security doors, shot blasting equipment and tumbling machine
Containers
Construction
Lifting and mobile equipment
Construction of bridges
Wearing plates
Chemical
Oil & Gas
Pylons and other architectural structures
Power Generation
Framework structures
Stone or iron chutes
Automotive
Heavy Equipment
Steel constructions
Crane booms
Machine building
Truck frames
